The Sansui No.T1 Line
Models 221, 331, 551 , 661, 771, and 881
Each Number 1 in its class.
You are looking up to the finest stereo receivers today's technology can produce.
Each a leader in its class. From the 8 and 12 watts per channel minimum RMS into 8 Ohms load from 40 Hz to 20 kHz with no more than 1.0% total harmonic distortion for the new Sansui 221 and 331 to the 63 wafts per channel, minimum RMS into 8 Ohms from 20 Hz to 20 kHz with no more than 0.3% total harmonic distortion for the full-feature top of the line Sansui 881. From $169.95 to $529.95, every Sansui delivers sophisticated electronics, flawless styling and superb convenience.
You can enjoy listening to them at your franchised Sansui dealer.
For even more enjoyment, you can own One.
SANSUI ELECTRONICS CORP.
Woodside, New York 11377 Gardena. California 90247
SANSUI ELECTRIC CO LTD . Tokyo, Japan
SANSUI AUDIO EUROPE S A Antwerp, Belgium ELECTRONIC DISTRIBUTORS ( Canada)_
Turn on the Fisher.
You'll get a 3-head Dolby deck that leaves you some money for tape.
There's no way-to know exactly what you're recording unless your tape deck has a third head for monitoring. But three-head cassette decks have always cost a lot of money.
Not any more Now there's the Fisher CR-5010. Its suggested retail price is just $229.95, and it has every thing you need.
The monitor head lets you listen to sound immediately after it's recorded. So you can be sure that your connections are secure, your mikes are in the right place, and your levels are OK. Dolby noise reduction cuts down the hiss and greatly improves the signal-to-noise ratio. Switchable equalization makes the most of the new tapes. And there's automatic shut-off and a precision pause control to make it all convenient.
You can spend a lot more for a 3-head Dolby deck. But if you want the most music for your money, turn on the Fisher CR-E010.
Fisher, 11-40 45th Road, Long Island City, N.Y. 11101
BOSE ON QUALITY
The 1801 Power Amplifier.
Much of the quality that distinguishes a truly outstanding electronic instrument from the average product goes unseen. It lies it the concern and skill of the design engineer, conservative rating of components, and extreme care in manufacturing.
For example, power transistors are costly. Yet using a large number assures that each works within its safe-area rating under any load and signal conditions. The 1801 uses 2b such power transistors.
A large power transformer is costly and heavy. In the 1801 the transformer is very large to provide tight regulation of supply voltages, providing very large power output with minimum stress on the output transistors.
Large amplifiers undergo unusual stresses during turn-on. The 1801 has a relay operated start-up circuit that limits currents and voltages in the power supply circuits during turn-on.
Yet what is on the surface perfectly complements the underlying quality of construction and design. 1300 square inches of heat sink. Two oversize VU meters.
A two-position in 3ut selector. Individual gain controls for each channel. A three-position speaker selector. And a light emitting diode display of power output.
The size, power and features of the 1801 are not for everyone. But for the nearest approach to the ultimate... in quality of design, construction, and performance ... there is no other amplifier.
The 1801. By Bose.
The Mountain, Framingham, Mass. 01701, USA.
Winston brings you The Box.
Warning: The Surgeon General Has Determined That Cigarette Smoking Is Dangerous to Your Health.
The Box brings you Fisher Quad.
Fisher Quad System from Winston Box.
Only $ 449.00. An $849 value. Manufacturer's Suggested Retail Price
Relax, flip on the Fisher Quad. Reach out, flip open The Winston Box. Let four speakers surround you in sound while you light up and enjoy Winston. The sound is real enough to touch. The pleasure is real enough to taste. Fisher Quad and The Winston Box.
They're both for real.
Winston/Fisher Quad System
Pease send me the Fisher Quad, complete with the Fisher guarantee.
Winston Boxes.
Offer available to persons 21 years of age or over. Allow 4-6 weeks for delivery Offer expires 12/31/75 Offer good in U S A Void where prohibited
The Fisher 220X Automatic Turntable with Diamond Stylus and Dust Cover
Crown POWER reveals a new level of listening.
Discover the five elements of Crown power that make hearing the DC300A such a unique listening experience.
Extreme low distortion:
Maximum total harmonic and intermodulation distortion of 0.05% over a bandwidth of 1-20,000 Hz. Such minute levels made it necessary for Crown to design its own intermodulation distortion analyzer, now in use industry wide.
Continuous power:
155 watts/channel minimum RMS into 8 ohms stereo, 310 watts minimum RMS into 16 ohms mono, over a bandwidth of 1-20,000 Hz.
Complete protection: The DC300A is fully protected against shorted loads, mismatched connections, overheating and excessive line voltage, input overload as well as RF burnout. And this amp will drive any type load, resistive or reactive.
Uncommon reliability: The DC300A's big name rock groups demand DC300A's be cause of their rugged ability to withstand tour-long punishment and still produce flawless sound.
And major recording studios insist on Crown to keep time losses at a minimum. The professionals know from experience Crown's unqualified dependability.
Exclusive warranty: Crown's unique warranty covers not only parts and labor but round-trip shipping for three years. These shipping costs are an important factor in our warranty, and it is not surprising that no other amplifier manufacturer offers this service.
For color brochure, write Crown, Box 1000, Elkhart, IN 46514.
For the most sensational sound demo of your life, take your best material to the nearest Crown dealer.
Crown—When Listening BECOMES an Art.
Technics by Panasonic
Many receivers may give you all this.
But they cost a lot more.
Technics SA-5150 Power and Price
At $229.95, the SA-5150-one of four new Technics stereo receivers-gives you more power and less THD than the five best selling brands do at a comparable price (16 watts per channel, minimum RMS, into 8f/from 40Hz to 20kHz, with no more than 0.8% total harmonic distortion).
Large Capacitors in Power Supply
You'll hear all the lows of the bass guitar and all the highs in the crashing of cymbals the way many receivers won't let you hear them-without distortion. Because the SA-5150 uses 4700,uf electrolytic capacitors in the balanced positive and negative power supplies. So you get the reserve power you need when you need it most.
Direct Coupling
For a tighter, cleaner, more rounded bass. Because the SA-5150's amplifier output is directly coupled to the speaker terminals with no capacitors in between. So you get more power output as well as a higher damping factor in the low frequency range. And the SA-5150 is one of the few receivers in its price range with direct coupling.
Phased Lock Loop IC in FM PLL improves stereo separation by maintaining precise phasing in FM. And to help keep distortion down to a point where you won't hear it (0.4%), the SA-5150 uses flat group delay ceramic filters in the IF section. There's also a sophisticated front end that delivers a selectivity of 70d3, 1.907 sensitivity and a capture ratio of 1.8dB.
So if you want a receiver with large capacitors in the power supply. Direct coupling. Phase Lock Loop in FM. And 16 watts RMS at $229.95.
There's only one receiver you want. The SA-5150.
The concept is simple. The execution is precise.
The performance is outstanding. The name is Technics.
FOR YOUR TECHNICS DEALER, CALL TOLL FREE 800 447-4700.
IN ILLINOIS, 800 322-4400.
Technics by Panasonic
Sony V-FETs
While everyone is still trying to make V-FETS at any price, we now make them at a lower price.
When Sony introduced the first amplifiers with vertical field-effect transistors last year, the reactions were nothing short of incredible.
Consumers wrote in asking where they could hear the equipment. Audiophiles demanded to know where they could buy it. And our competitors wanted to know how they could make it.
In fact, the only problem was that more people couldn't afford the $1300 price.
So, we at Sony decided to do something about it.
And what we've come up with is our new $400 V-FET integrated amplifier, the TA-4650. The TA-4650 is quite an advanced little piece of equipment. Because the V-FET isn't just another combination of gadgets, or a souped-up version of the same old thing. It's a completely new device that combines the good points of both bi-polar transistors and triode vacuum tubes.
Without suffering the drawbacks of either. Because it's made with V-FETS, the TA-4650 gives you a new level of highly defined triode sound; along with the efficiency and stability found only in solid state devices.
The TA-4650 delivers 30 watts per channel, minimum RMS at 8 ohms, 20Hz-20kHZ with no more than 0.1% total harmonic distortion.
It has a direct coupled power amplifier stage. As well as direct coupled FET amplifiers in the tone control and buffer stages.
Its bass and treble controls have a turnover frequency selector that starts at 250HZ/500HZ for bass and 2.5kHZ/5kHZ for treble.
Its volume control is equipped with a switch for 20dB muting. And it has a level control memory device so volume can be set at any predetermined point.
But as good as our new V-FET amplifier is, we're just as proud of the components we make to go along with it.
Our ST-4950 AM/FM stereo tuner, for example, has a MOS FET front end, uni-phase solid state filters and IC's in IF stages. This allows an FM capture ratio of only 1.0dB, selectivity of 80dB and an S/N ratio of 70dB. The ST-4950 also has a phase-locked loop (PLL) MPX section. Which means you get excellent stereo separation and low distortion.
Of course, if you're going around looking for a turntable, by all means take a look at our PS-4750 (cartridge sold separately).
It has a direct drive servo motor with a wow and flutter rating of only 0.03%.
Its base and platter are made from molded compound instead of metal, so resonance has been greatly reduced. It also has air-damped cushions, which compensate for warpness in records (again reducing resonance). The end result is a much cleaner sound.
It's no accident that Sony makes the world's first commercially available V-FET equipment. Or that we have matching components good enough to complete your system.
You see, we've got more solid state audio experience than anyone else. We've been at it for twenty years. For proof just stop by your Sony dealer.
And use your ears.
TA-8650, 80 watts per channel, min. RMS 8 ohms. 20Hz-20kHz, with no more than 0.1% total harmonic distortion.
SONY--1975 Sony Corp of America
Sony, 9 W 57 St., N.Y. N.Y 10019
FRAZIER...
A DIFFERENCE YOU CAN HEAR
At Frazier, we build loudspeakers to deliver the very finest sound. Match less sound. We've been designing speakers to deliver that kind of excellence for over 30 years.
We've learned the difference between good sound and superlative sound.
That difference is incorporated into every Frazier loudspeaker. It began as a matter of pride, now it's a matter of practice.
Because through the years, more and more people who care about a better sound, have come to Frazier to find it.
And they keep coming back, year after year.
We have a unique line of loudspeakers to suit your every mood, and every decor. From the Concerto, with smooth as silk reproduction with a 10" heavy duty woofer and special high frequency horn, to the Seven, with a 12" woofer, two 4" midrange speakers and two special high-frequency horns. Frazier also offers the incomparable Super Midget, Monte Carlo Mark IV-A, Mark V and Mark VI.
Whichever you choose, you have found the most outstanding reproduction possible. If it were anything less, we wouldn't call it Frazier.
For a demonstration on the loudspeaker with the difference, see your nearest Frazier dealer today.
Frazier INCORPORATED, 1930 Valley View Lane Dallas, Texas 75234, Phone 214-241-3441
Dolby FM is happening
Remember the first time you came across Dolbyized cassettes? And how surprised you were that music could sound so good in such a convenient form? Well, now the same principles are being used to improve FM broadcasting. The audible effect of the Dolby system as used in FM is a bit more subtle than with cassettes. But the overall results are just as important. Dolby FM is cleaner, with sparkling high frequencies free of limiting.
And, of course, noise is reduced, which often increases the area of good reception.
As of August 1975, over 100 US stations have purchased the Dolby Model 324 or 334 FM Broadcast Encoder. (The encoder accurately compresses the signal in accordance with the Dolby B-Type characteristics and changes the effective transmission time-constant to 25 microseconds. At the same time, the station eliminates any high frequency limiting required previously).
As you can hear for yourself, a Dolby FM signal is compatible. In fact, most people find it a better signal even when received on their normal equipment without Dolby decoding.
However, you may be the kind of person who likes to take advantage of every opportunity for improvement. If you use Dolby circuitry during reception, you can bring the signal even closer to the quality of the original source material.
Naturally, the noise is reduced. But that's not all. Dolby compression is standardized, recoverable compression.
By using Dolby encoding instead of the conventional high frequency limiting normally required during transmission, the station gives the listener at home the opportunity of recovering the full frequency range and dynamics of the signal.
If these prospects excite you, we think you will soon be wanting to check out the new generation of receivers with built-in Dolby circuitry.* Some Dolby licensees are already producing their new models, and others have new designs in the pipeline.
-------------
Akron OH WAEZ 97 5 Cincinnati OH WGUC 90.9 Edmond OK KWHP 97.7 Los Angeles CA KGBS 97.1 New York NY WQXR 96.3 Seattle WA KIXI 95 7 Albany NY WHSH 106.5 Collegeville MN KSJR 90.1 Fairmont NC VVFMO 100.9 Los Angeles CA KI00 100.3 New York NY WRFM 105.1 Skokie IL WCLR 101.9 Allentown PA WFMZ 100.7 Columbus GA WEIZ 100.1 Flint MI WGk1Z 107 9 Los Angeles CA KPFK 90/ Normal IL WGLT 91.7 St. George SC WPWR 959 Alta Vista VA WKDE 105.5 Columbus OH WCOL 923 Fort Wayne IN WkIEF 97.3 Lancaster PA WDAC 94.5 Opportunity WA KZUN 96.1 St. Louis MO KCFM 937 Arlington TX KAMC 94.9 Columbus OH WOSU 98.7 Fort Worth TX KWXI 97.1 Lexington VA WLUR 91.5 Paterson NJ WPAT 93.1 Stevens Point WI WSPT 979 Baltimore MD WAMR 106.5 Dayton OH WTUE 104 7 Fresno CA KPHD 955 Louisville KY WCSN 99.7 Philadelphia PA WMMR 93.3 Sylvania OH WOES 105 5 Birmingham Ml WHNE 94.7 Dallas TX KCHU 90.9 Gainesville GA VVCLN 106 7 Louisville KY WLRS 102.3 Portland ME WDCS 97.9 Topeka KS KTPK 106.9 Boston MA WROR 98.5 Dallas TX KTLC 100.3 Grand Rapids Ml WZZM 95.7 Madison WI WYXE 92.1 Richmond VA WEZS 103.7 Tuscaloosa AL WUOA 95 7 Boston MA WVBF 105.7 Dallas TX KVIL 103.7 Hanover NH WDCR 99.3 Maine FL WAIA 97.3 Rochester NY WCMF 96.5 Utica NY WOUR 96.9 Buffalo NY WDCX 99.5 Dallas TX KZEW 97.9 Hartford CT V1i TIC 965 Manassas VA WEZR 106.7 Rochester NY WEZO 101 3 Washington DC WAMU 885 Buffalo NY WBEN 102.5 Denver CO KBPI 105.9 Henrietta NY WITR 89.7 Memphis TN WKNO 91.1 Saline MI WIOB 102.9 Washington DC WASH 97.1 Carbondale IL WSIU 91.9 Denver CO KLZ 106 7 Houston TX KILT 100.3 Miami FL WAIA 97.3 Salt Lake City UT KDAB 101.1 Washington DC WGMS 107 3 Charlotte NC WEZC 104.7 Detroit MI WABX 99.5 Houston TX KRLY 93 7 Minneapolis MN KSJN 91.1 Salt Lake City UT KSL 100.3 Washington DC WHUR 96.3 Charlotte NC WROQ 95.1 Detroit MI WOMC 104.3 Indianapolis IN WNAP 93.1 Morgantown WV WAJR 101.9 San Antonio TX KEXL 104.5 Washington DC WMAL 107 3 Chicago IL WFMT 98.7 Detroit MI WJZZ 105.9 Jackson MS WSLI 96.3 New Orleans LA WEZB 97.1 San Diego CA KGB 101.5 Wilkes-Barre PA WYZZ 92.9 Chicago IL WLOO 100.3 Detroit Ml WMUZ 103.5 Kettering OH WVL:D 99.9 New Orleans LA WNOW 101 1 San Francisco CA KABL 98.1 Youngstown OH WYSU 88.5 Cincinnati OH WEBN 102.7 Detroit MI WORS 105 1 Los Angeles CA KBIG 104 3 New York NY WNEW 102.7 Seattle WA KIRO 100.7
---------------
Dolby FM is an improvement we think you will appreciate. And it's happening.
'If you enjoy doing your own hook-ups, you can use an add-on Dolby unit, aided by a simple circuit to change your receiver time-constant to 25 microseconds.
Dolby Laboratories Inc., Dolby and the double-D symbol are trade marks of Dolby Laboratories Inc.
1133 Avenue of the Americas New York NY 10036
Telephone (212) 489-6652
Telex 125797 Cables Dolby labs New York
346 Clapham Road London SW9
Telephone 01-7201111
Telex 919109 Cables Dolby labs London
Stanton
Instant Success-- the NEW Stanton Gyropoise turntable. Look at all these quality features, many of them Exclusively ours!
1. Gyropoise-frictionless magnetic suspension of the platter.
2. Die cast aluminum T-Bar for sturdy structure.
3. 2-Speed changer for 33 rpm and 45 rpm playback.
4. 24-Pole synchronous high torque motor.
5. Belt drive for noiseless operation.
6.12" die cast machined high polish .aluminum platter.
7. Unipoise '-single point tone arm suspension.
8. Anti-skate control adaptable to all types of styli.
9. Magnetic hold bar for tone arm convenience.
10. Stylus force slide (range 0--4 grams).
11. Stanton state-of-the-art stereo or discrete cartridge.
12. Viscous damped cueing control for feather-light lowering of stylus.
13. Handsome walnut veneer base (comes complete with dust cover).
ADDITIONAL FEATURES:
(a) Comes equipped with low capacitance cables (b) Wow and Flutter-< .07% din 45507 weighted (c) Rumble---60 dB din 45539 weighted It's the important exclusive features that make the difference.
Only Stanton Turntables have Gyropoise, the patented frictionless magnetic suspension bearing-thus the platter makes no vertical contact with the body of the structure. This isolation eliminates vertical rumble.
Only Stanton Turntables have Unipoise, the patented single point tone arm suspension. The arm is supported by a single pivot for both lateral and vertical movement.
Only Stanton Turntables come equipped with a state-of-the art Stanton cartridge, either the 681 Triple-E calibrated to the tone arm for stereo playback, or the magnificent 780/4D0 for discrete.
Bottom view shows simplicity )f See your franchised Stanton dealer for a demonstration of this great new product.
MADE IN U S A For further information, write: Stanton Magnetics, Inc., Terminal Drive, Plainview, N.Y. 11803. Stanton
AKG
A lot of headphones hurt. After a few minutes they begin to weigh you down. A few minutes longer, and they start building a tiring pressure on your ears. They hurt too much to keep on your head.
Or you can slip on the new lightweight AKG K-140 headphones. They automatically adjust to the contour of your head. (With our exclusive Cardair swivel and supra-aural design, the 140 doesn't have to make a squeeze fit.) So there's no ear pressure. And no thumping head. You can listen for hours. Painlessly.
The 140 also lets you enjoy music at high sound levels without punishing your ears.
Yet, you can hear your environment because the 140 won't isolate you. After all, music isn't played in a vacuum. But don't worry, no one will be disturbed when you wear a 140.
We designed the 140 for professional monitoring. Which means wide bandwidths and low distortion, and sound pressure levels over 115 dB. The 140 is compatible with all outputs, 4-600 ohms. Weight: a scant 6.2 ounces. Price? That's so scant it won't give you a headache either. $34.50.
AKG MICROPHONES HEADPHONES distributed by:
PHILIPS AUDIO VIDEO SYSTEMS CORP., AUDIO DIVISION, 91 McKee Drive, Mahwah, New Jersey 07430.
A North American Philips Company
The headphone without the headache.
Introducing the AKG K-140.
Yamaha
THE END OF THE DOUBLE STANDARD.
OUR LEAST EXPENSIVE RECEIVER LOW DISTORTION AS OUR MOST HAS THE SAME EXPENSIVE RECEIVER
At Yamaha, we make all our stereo receivers to a single standard of excellence.
A consistently low intermodulation distortion of just 0.1%! A figure you might expect only from separate components. Maybe even from our $850 receiver, the CR-1000.
But a figure you'll surely be surprised to find in our $330 receiver, the CR-400.
So what's the catch? There is no catch. Simply a different philosophy. Where high quality is spelled low distortion.
You'll find Yamaha's single mindedness particularly gratifying when compared to the amount of distortion other manufacturers will tolerate throughout their product lines.
(See chart.) Particularly gratifying and easily explained.
Less of what irritates you most.
While other manufacturers are mostly concerned with more and more power, Yamaha's engineers have concentrated IM Distortion Comparison YAMAHA Brand "A" Brand "B" Brand "C"
CR-1000 .1% .1% .15% .3%
CR-800 .1% .3% .3% .5%
CR-600 .1% .5% .5% .8%
CR-400 .1% 1.0% .9% 1.0%
With most manufacturers, price determines quality. However, in the above chart, you can see how Yamaha alone offers the same quality (low distortion) throughout our entire line, regardless of price, on less and less distortion.
Particularly intermodulation (IM) distortion, the most irritating to your ears. By virtually eliminating IM's brittle dissonance, we've given back to music what it's been missing.
A clear natural richness and brilliant tonality alone cannot describe. A new purity in sound reproduction.
A musical heritage.
Our seeming preoccupation with low distortion, in general, and the resulting low IM distortion, in particular, stems from Yamaha's own unique musical heritage.
Since 1887, Yamaha has been making some of the finest musical instruments in the world.
Pianos, organs, guitars, wood winds, and brass.
You might say we're music people first.
With our musical instruments, we've defined the standard in the production of fine sound. And now, with our entire line of receivers and other stereo components, we've defined the standard of its reproduction.
Four different receivers, built to one standard.
Between our $330 CR-400 and our $850 CR-1000, we have two other models.
The $460 CR-600 and the $580 CR-800.
Since all are built with the same high quality and the same low distortion, you're probably asking what's the difference.
The difference is, with Yamaha, you only pay for the power and features that you need.
Unless you have the largest, most inefficient speakers, plus a second pair of the same playing simultaneously in the next room, you probably won't need the abundant power of our top-of-the-line receivers.
Unless you're a true audiophile, some of the features on our top-of-the-line receivers might seem a bit like gilding the lily. Selectable turnover tone controls, variable FM muting, two-position filters, even a special five-position tape monitor selector.
However, you don't have to pick one of Yamaha's most ex pensive receivers to get a full complement of functional features as well as our own exclusive Auto Touch tuning and ten-position variable loudness control.
The End of the Double Standard.
Just keep in mind that all Yamaha stereo receivers, from the most expensive to the least expensive, have the same high quality, the same low distortion, the same superlative tonality.
It's a demonstration of product integrity that no other manufacturer can make. And, an audio experience your local Yamaha dealer will be glad to introduce you to.
YAMAHA International Corp., P.O. Box 6600, Buena Park, Calif. 90620
ADS
Invisible Sound, Compact and Powerful.
The ADS L710 and L810 are four driver, three way speakers for audiophiles who demand studio performance from a system that is still compact enough for bookshelf placement. These systems share exceptionally wide-range frequency and power response that places them in the small select group of reference quality speakers without demanding the usual penalty of size and price.
We invite you to test them against any high quality speakers regardless of cost.
Lister, how accurately the virtually massless 1" soft-dome tweeter follows every detail of a solo violin.
Notice how uniformly the unique mid-range driver reproduces the subtleties or a familiar voice-no brassy sound ever; instead, un-muffled openness. The 2" soft dome smoothly radiates nine times as much power into a hemisphere ADS 110 as a conventional speaker of the same area.
Then train your ears on the woofers. They are small in diameter for optimum transient and power response; this extends clarity and detail down into bass. It is elegantly accomplished by two active, perfectly phased drivers with unprecedented lateral excursion. You never before heard a bass drum come so much alive.
Flawless consistency in all these qualities is our uncompromising standard of excellence, and it is built into every model from ADS.
Your local ADS dealer will proudly demonstrate the L710 and L810 in his sound studio. Take the time and test them critically. Take the step beyond transparency. Experience "Invisible Sound." It then will be Impossible for you to accept anything less.
Analog & Digital Systems, 64 Industrial Way, Wilmington, Massachusetts 01887.
Also see:
Misc. ads collected (March 1977)
harman/kardon ST-7 tanget tracking turntable
Source: Stereo Review (USA magazine)
