Eccentricity
I was glad to see the subject of poor record pressings taken up in your column for July, because the scratched and dirty condition of many of the records I obtain from domestic sources has led me over the last several years to import most of my purchases from England, Germany, and Japan.
If the difficulty with off-center records were due to an off-center hole, as your correspondent complains, both sides of the record would be off in the same direction and of course by the same amount; this has almost never been my experience, and I am plagued by records well enough centered on one side only.
How much eccentricity ought to be tolerated? It is easy to show (and easier to hear) that the effect on the pitch of the music is greatest at the end of a side, where the radius is at least 60 mm. Nowadays a turntable wow specification of 0.1% is respectable, and applying this as a standard would require records to be no more than 0.06 mm. off.
A record off by this amount will cause the pickup arm to oscillate over a distance of 0.12 mm. as the record rotates, and this is about the smallest motion which can be measured easily on fine pitch recordings. In my collection the records which meet this standard are the older ones and those made in Germany, with those made in England running a close second.
Which turntable manufacturer will be the first to provide a conveniently adjustable eccentric spindle?
-J. D. REED, Chicago
Eccentricity used to be more prevalent in England, but seriously, the problem lies with the record manufacturers and it should not be passed to the record player designers for a solution.
-ED.
Integrity
In the midst of all the electronic marvels of today and tomorrow at the EIA/Consumer Electronics Show, it was an unexpected pleasure to see that at JBL they still care about the guy who bought last year's model. Their new tuner will have interchangeable fronts, one of which will match their discontinued SA 600 integrated amp. That's a kind of integrity consumers seldom see. I appreciate it, JBL, I'll bet others do too.
--DAVID S. MONETT, Elmhurst, N.Y.
To JBL's President, Arnold Wolf--take a bow...
More on Doppler
I found the article on Doppler distortion by Roy Childs very interesting indeed. Little has been published on this subject-most experts apparently taking the view that Doppler distortion does not exist, or if it does, it is not significant.
As far as I know, Paul Klipsch is the only one who has really investigated the problem, but unfortunately his articles in the AES Journal and elsewhere are spoiled by his `blowing the trumpet' for horn systems. Perhaps you can persuade him to write a factual article without the propaganda?
--James Russell, Bridgeport, Conn.
Well, we did manage to persuade Paul to write an article for us although I must admit, the faint but persistent sound of a trumpet can be heard in the background! Years ago, most experts did tend to disregard the Doppler effect. The late Henry Hartley, one of the early pioneers said in a letter to me in 1961, "1 had a magnet design which avoided cross-modulation, mistakenly called the Doppler effect." He did in fact carry out a series of experiments which proved that certain spurious combination tones were caused by nonlinear voice-coil excursions relative to the magnetic field. The present interest in Doppler distortion--or as Paul has it, modulation distortion-is due to the advent of bookshelf speaker systems using small speakers which necessarily have large-amplitude cone movements to produce a reasonable base.
-ED.
===========
Editor's Review
Speaking at a meeting of the prestigious International Tape Association, Virginia Knauer, Special Assistant to President Nixon for Consumer Affairs, said "If the Tape Industry does not attempt to clean up its own shop, there will be a time when the option will no longer be yours" Strong words-which provoked swift replies from those who disagreed. Said Joseph Tushinsky, president of Sony-Superscope, "I don't think she knows what she's talking about." He went on to say that the industry has standardized already as far as tapes, microphones, and connectors were concerned. Jeff Berkowitz of Panasonic said the industry was almost completely standardized and that it was possible for anyone to buy a stereo 8 cartridge, cassette, or open-reel tape and play it on any manufacturer's machine. True enough, but when Virginia mentioned the lack of standardization for 4-channel and video tapes, she had a point.
Her criticism of poorly-defined warranties was probably justified but I am not certain I would agree that "there is a lack of information concerning recorders and service facilities are poor." Talking about standardization reminds me that very soon we will be confronted by a number of quadraphonic record systems-each with its own `black box' decoder to convert the two composite channels back to the original four. One of the latest to appear on the scene is from the Japanese Victor company ( JVC) and the leaflet makes the rather delightful statement, "The difference between two-channel and four-channel sound is the difference between a shower and a proper bath." Presumably, mono would be equivalent to washing under the pump.... Trouble, is-manufacturer A's Black Box will not work with manufacturers B's system and vice versa! Incidentally, the JVC system features carrier modulation with frequency modulated low frequencies and phase modulation above 800 Hz.
---
Doctor Van Kiunge of the Hague, Holland, has invented a loudspeaker system based on the human throat. Says the good Doctor, "The human vocal system is very efficient and it is logical to use the principles for a loudspeaker."
---The New York Audio Society ( 215 Adams St., Brooklyn, N.Y. 11201) announces an interesting meeting for November 11. The guest speaker is Martin Bookspan, of ASCAP and the place is the Dragon Seed restaurant, Jackson Heights, Queens.
Time: 8:00 p.m.
----
Harold Leak is of course well-known as one of the pioneers of Hi-Fi. In 1946 he designed an amplifier with the very low distortion of 0.1%-and so it was designated the Leak Point-One. A few months ago, Harold decided to retire and so he sold his business to the Rank-Wharfedale group.
Now I learn that Harold has bought himself a yacht which he has named-you guessed it-the Point-One. . . May he enjoy his retirement for many years. The same goes for Alexander M. Poniatoff of Ampex, who now retires at the age of 82.
He founded Ampex in 1949 and the name is taken from his initials, plus, he says-EX for excellence.
--- At the end of the magazine is a Reader Service Card ( known to the initiated as a "Bingo" Card) . Observant readers will note that some questions have been added such as "Do you want more record reviews? What kind? More technical articles? Constructional articles? and so on. You may not want information regarding X speakers or Y receivers at this time, but please take a few minutes to fill in the rest of the card-it will be appreciated.
----
Many readers have been annoyed by the asterisks in "Tape Guide" and "Audioclinic." This kind of thing: "I have been using a ---- machine with a ---- amplifier and...." Infuriating. From now on, we will print the names--so if you have a ----- tape recorder-you'll know it!
-G.W.T.
